Dental Microscope Alltion AM5000

Price: contacts us for price

Alltion AM-5000 operating microscopes are quality instruments that enable operations or procedures to be performed comfortably and professionally.

The ergonomic design enables one-handed control of the microscope and focus by turning the focus wheel with your thumb. Various choices of stands will allow you to find the right option for many cabinets. Also, the optical axis of the lens can be rotated left/right in relation to the eyepieces (accessory FORA - Flexible Optics Rotating Assembly)

The lens has a continuously variable working distance of 198-455 mm. The excellent construction eliminates over 90% of the stray light that interferes with the work, and the full coating of the lenses with multi-layer anti-reflection coatings improves the light transmission by about 20% compared to a single layer coating.

The microscope has a power supply for additional devices with 12V and 5V outputs. You won`t have to worry about the condition of additional devices` batteries.

The cables are routed inside the case - if they are not on the outside, they will not catch on anything, the microscope can be moved without the resistance of the stretched wires, it looks beautiful and can be perfectly integrated into the clinic environment.

The microscope is of a modular design, so fault diagnosis and repair processes are simple and therefore do not take long - these are excellent features to ensure reliable operation.

AM-5000 microscopes are supplied with built-in cameras specially made for them. These are instruments with excellent features at a good price, perfectly complementing the capabilities of the device.

Specifications:
Magnification Type: Manual 6-step Variable Magnification
Magnification range: 1.4X-22.8X
Eyepiece angle: adjustable 0-180 degrees
Distance between eyes: 50-75 mm
Eyepieces: 12.5X/18mm, 10X/21mm optional
Lens quality class: apochromatic
Diopter adjustment range: +/-7D
Lens: 198-450mm working distance lens
LED lifetime: >50,000 hours
Light intensity: Max. 80,000lx with 250mm lens
CRI: >=85%
Color temperature: 5500K
Support system: Ceiling Mounted/Wall Mounted Low/Wall Mounted High/Floor Mounted/Table Mounted/Mobile Stand
Camera: Built-in 4k camera
Camera sensor: 1/1.8`` SONY 8MP CMOS Interfaces: HDMI 2.0, USB 2.0, USB 3.0, 3.5 mm audio
Resolution: 4k (3840x2160) 60FPS (16:9)
Storage: connect external USB storage devices (FAT32 or NTFS formats supported)
WiFi: Built-in WiFi functionality, can transmit images
Video resolution: 4K 30FPS, 1080P 30FPS
Photo resolution: 8MP (3840x2160), 2MP (1920x1080)
